DS-J1421/7108HGHI-F1/N+8CAM
824.00 ლარი
8-ch 1080p Mini 1U Lite H.264 DVR
8 channels and 1 HDD mini size DVR
H.264+ / H.264 video compression
Encoding ability up to 1080p lite @ 12 fps
5 signals input adaptively (HDTVI/AHD/CVI/CVBS/IP)
Up to 10 network cameras can be connected;
1 x DVR power supply
8 x Bullet Cameras - DS-2CE16C0T-IR
1 x Camera Power supply
4 x 20 Meter camera cables, all connectors are pre fitted
SKU / პროდუქტის კოდი: 06088კატეგორია: პროდუქცია • ვიდეო სისტემები • HD TVI კომპლექტები
ტეგები და ატრიბუტები:
HD TVI კომპლექტები 1080p Kit
აღწერა
- Recording
- Video compressionH.264+/H.264
- Encoding resolutionWhen 1080p lite mode not enabled: 720p/WD1/4CIF/VGA/CIF When 1080p lite mode enabled: 1080p lite/HD 720p lite/WD1/4CIF/VGA/CIF
- Frame rateMain stream: When 1080p lite mode enabled: 1080p lite/HD 720p lite/WD1/4CIF/VGA@12fps; CIF@25fps (P)/30fps (N) When 1080p lite mode not enabled: For 720p stream access: 720p/WD1/4CIF/VGA@12fps; CIF@25fps (P)/30fps (N) For SD stream access: WD1/4CIF/VGA/CIF@25fps (P)/30fps (N) Sub-stream: CIF/QVGA/QCIF@25fps (P)/30fps (N)
- Video bit rate32 Kbps to 4 Mbps
- Dual streamSupport
- Stream typeVideo, Video & Audio
- Audio compressionG.711u
- Audio bit rate64 Kbps
- Video and Audio
- IP video inputUp to 8-ch Up to 960p resolution Support H.264+/H.264 IP cameras
- Analog video input8-ch BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
- Turbo HD input1080p25, 1080p30, 720p25, 720p30
- AHD input1080p25, 1080p30, 720p25, 720p30
- HDCVI input1080p25, 1080p30, 720p25, 720p30
- CVBS inputSupport
- Audio input1-ch, RCA (2.0 Vp-p, 1 KΩ)
- Audio output1-ch, RCA (Linear, 1 KΩ)
- Two-way audioReuse the first audio input
- Synchronous playback8-ch
- VGA/HDMI output1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
- Network
- Remote connections128
- Network protocolsTCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS
- Network interface1, RJ45 10M/100M self-adaptive Ethernet interface
- Auxiliary interface
- SATA1 SATA interface
- CapacityUp to 6 TB capacity for each disk
- Alarm in/outN/A
- USB interfaceRear panel: 2 × USB 2.0
- General
- Power supply12 VDC
- Consumption (without HDD)≤ 12 W
- Working temperature-10 °C to 55 °C (14 °F to +31 °F)
- Working humidity10% to 90%
- Dimensions (W × D × H)200 × 200 × 45 mm (7.9 × 7.9 × 1.8 inch)
- Weights (without HDD)≤ 0.8 kg (1.8 lb)
გადმოწერა
|
|
Up to 10 network cameras can be connected;
1 x DVR power supply
8 x Bullet Cameras - DS-2CE16C0T-IR
1 x Camera Power supply
4 x 20 Meter camera cables, all connectors are pre fitted)
