DS-N208P
464.00 ლარი
8-channel IP recorder
• 8 channels
• Recording with a resolution of up to 4MP
• Video output with a resolution of up to 4MP
• Synchronous playback of 2 channels @ 1080p
• 1 SATA HDD up to 6TB
• 1/1 audio input / output
• Network interface 1 RJ-45 10M / 100M Ethernet
SKU / პროდუქტის კოდი: 11224კატეგორია: პროდუქცია • ვიდეო სისტემები • ქსელური ჩამწერები
ტეგები და ატრიბუტები:
IP ჩამწერები 4MP
აღწერა
Video / audio input
Video compression format |
H.265 + / H.265 / H.264 + / H.264 |
IP cameras |
8 channels |
Incoming bandwidth |
60 Mb / s |
Outgoing bandwidth |
60 Mb / s |
Video / Audio Out
Video output |
1 HDMI, 1 VGA |
Output resolution |
1920x1080 / 60Hz 1280x1024 / 60Hz 1280x720 / 60Hz 1024x768 / 60Hz |
Record
Number of threads |
2 |
Main stream |
4MP / 3MP / 1080p / 1.3Mp / UXGA / 720p / VGA / 4CIF / DCIF / 2CIF / CIF / QCIF, 1/16 fps ~ 50k / s |
Additional stream |
VGA / 4CIF / CIF / QVGA, 1/16 fps ~ 25k / s |
Stream type |
Video, video and audio |
Bitrate video |
32-16384 Kbps |
Synchronous playback |
1 channel @ 4MP, 2 channels @ 1080p |
HDD
SATA |
1 SATA |
Volume |
up to 6 Tb |
Interfaces
Network interface |
1 RJ-45 10M / 100M Ethernet |
Independent PoE Interfaces |
8 independent PoE interfaces 10 / 100Mb / s, EXTEND PoE mode up to 250 m 10 Mbps Cat 5e |
PoE Budget |
75 watts |
Supported Standards |
IEEE 802.3af / at |
USB interface |
2 USB 2.0 |
General
Nutrition |
DC 48V |
Power consumption |
Up to 90 W (without HDD) |
Working conditions |
-10 ° C— + 55 ° C, humidity 10% ~ 90% |
The size |
285 × 215 × 48 mm |
Weight |
≤1 kg (without HDD) |
